3.7kw 11kw 15kw 22kw oil free scroll air compressors for Gas Chromatograph and Atomic absorption spectrophotometer

Product Categories
Shanghai Royal Machinery Co.,Ltd
Contact Now
    Buy cheap 3.7kw 11kw 15kw 22kw oil free scroll air compressors for Gas Chromatograph and Atomic absorption spectrophotometer from wholesalers

    Buy cheap 3.7kw 11kw 15kw 22kw oil free scroll air compressors for Gas Chromatograph and Atomic absorption spectrophotometer from wholesalers
    • Buy cheap 3.7kw 11kw 15kw 22kw oil free scroll air compressors for Gas Chromatograph and Atomic absorption spectrophotometer from wholesalers
    • Buy cheap 3.7kw 11kw 15kw 22kw oil free scroll air compressors for Gas Chromatograph and Atomic absorption spectrophotometer from wholesalers
    • Buy cheap 3.7kw 11kw 15kw 22kw oil free scroll air compressors for Gas Chromatograph and Atomic absorption spectrophotometer from wholesalers
    • Buy cheap 3.7kw 11kw 15kw 22kw oil free scroll air compressors for Gas Chromatograph and Atomic absorption spectrophotometer from wholesalers
    • Buy cheap 3.7kw 11kw 15kw 22kw oil free scroll air compressors for Gas Chromatograph and Atomic absorption spectrophotometer from wholesalers
    • Buy cheap 3.7kw 11kw 15kw 22kw oil free scroll air compressors for Gas Chromatograph and Atomic absorption spectrophotometer from wholesalers

    3.7kw 11kw 15kw 22kw oil free scroll air compressors for Gas Chromatograph and Atomic absorption spectrophotometer

    Ask Lasest Price
    Brand Name : RM
    Model Number : 1.5KW
    Certification : CE
    Price : $1830/unit
    Payment Terms : L/C, T/T
    Supply Ability : 10000units/month
    Delivery Time : 7days
    • Product Details
    • Company Profile

    3.7kw 11kw 15kw 22kw oil free scroll air compressors for Gas Chromatograph and Atomic absorption spectrophotometer

    1.5kw 2.2kw 3.7kw scroll oil free air compressor for oxygen generator

    Model NoRMC-0.17/8RMC-0.17/8-TRMC-0.24/8RMC-0.24/8TRMC-0.4/8RMC-0.4/8
    Air flow (L/min)170170240240400400
    Discharge pressure (Mpa)0.5-0.80.5-0.80.5-0.80.5-0.80.5-0.80.5-0.8
    Tank (stainless steel)/40/40/40
    Power (kw)1.51.52.22.23.73.7
    Speed (rpm)320032003200320032003200
    Voltage (v/hz)220/50 1P;380/50hz 3p220/50 1P;380/50hz 3p220/50 1P;380/50hz 3p220/50 1P;380/50hz 3p380/50hz 3p380/50hz 3p
    Noise (dB)46 ±346 ±348 ±348 ±350 ±350 ±3
    Way of coolingAirAirAirAirAirAir
    Way of controlAutomaticAutomaticAutomaticAutomaticAutomaticAutomatic
    Weight (kg)110190120200135210
    Dimension (mm)540*540*750540*540*1190540*540*750540*540*1190540*540*750540*540*1190

    Scroll oil free air compressors

    • 3.7kw scroll airend, 5.5kw scroll airend
    • 8bar 10bar
    • LCD controller screen display

    3.7kw oil free scroll air compressor paramters:

    • M-3.7/08-A1
    • Air capacity:0.4m³/min
    • Outlet pressure:0.8Mpa
    • Voltage:380v/50hz
    • Power:3.7kw
    • Noise:55±2dB
    • Speed:3200rpm
    • Weight:200kg
    • Dimension:810*690*880mm
    • Outlet connect:3/4”
    • _20190523104329_.jpg

    3.7kw oil free scroll air compressor with tank

    • MT-3.7/08-A1
    • Air capacity:0.4m³/min
    • Outlet pressure:0.8Mpa
    • Voltage:380v/50hz
    • Power:3.7kw
    • Noise:55±2dB
    • Speed:3200rpm
    • Weight:250kg
    • Dimension:1530*690*1450mm
    • Outlet connect:3/4”
    • _20190830110230_.jpg

    3.7kw oil free scroll air compressor with tank and dryer:

    • MT-3.7/08-A1
    • Airend Qty:1
    • Air capacity:0.4m³/min
    • Outlet pressure:0.8Mpa
    • Voltage:380v/50hz
    • Power:3.7kw
    • Noise level: 55±2dB
    • Speed:3200rpm
    • Weight:250kg
    • Dimension:1530*690*1450mm
    • Outlet connect:3/4”
    • 3_.jpg

    7.5kw oil free scroll air compressor parameters:

    • M-7.5/08-A2
    • Airend Qty: 2
    • Air capacity:0.8m³/min
    • Outlet pressure:0.8Mpa
    • Voltage:380v/50hz
    • Power:7.5kw
    • Noise level: 60±2dB
    • Speed:3200rpm
    • Weight:400kg
    • Dimension: 1130*960*1140mm
    • Outlet connect:3/4”
    • M-1108-S2.jpg

    5.5kw oil free scroll air compressor paramters

    • M-5.5/08-S1
    • Airend Qty:1
    • Air capacity:0.6m³/min
    • Outlet pressure:0.8Mpa
    • Voltage:380v/50hz
    • Power:5.5kw
    • Noise level: 55±2dB
    • Speed:3200rpm
    • Weight:220kg
    • Dimension: 810*690*880mm
    • Outlet connect:3/4”
    • _20190523104310_.jpg

    11kw oil free scroll air compressor parameters

    • M-11/08-S2
    • Airend Qty: 5.5kw*2
    • Air capacity: 1.2m³/min
    • Outlet pressure:0.8Mpa
    • Voltage:380v/50hz
    • Power:11kw
    • Noise level: 60±2dB
    • Speed:3200rpm
    • Weight:440kg
    • Dimension:1130*960*1140mm
    • Outlet connect:3/4”
    • 2.jpg

    22kw scroll oil free air compressor parameters:

    • M-22/08-S4
    • Airend Qty: 5.5kw*4
    • Air capacity: 2.4m³/min
    • Outlet pressure:0.8Mpa
    • Voltage:380v/50hz
    • Power:22kw
    • Noise level: 65±2dB
    • Speed:3200rpm
    • Weight:820kg
    • Dimension:1600*1250*1240mm
    • Outlet connect: 1”
    • 5.jpg

    Explosion view photo of oil free scroll airend:



    • The suited working environm ent for oil-free scroll com pressor
    • Medical and dental environment.
    • Required high quality air, no oil, no impurity.
    • Low noise, after-treatment equipment is unnecessary.
    • QQ20190830235745.png

    Scroll Compression Principle
    • Oil-Free Drain
    • High-precision processing technology is required to produce the components that make up a Scroll Compressor.
    • We have developed new Scroll Air-Ends thanks to the experience and know-how we have accumulated over the past 15 years.
    • As the orbiting scroll goes from No.1 to No.4 position, the size of the symmetrical crescent-shaped compression chambers is gradually reduced, compressing the air contained within . This is then discharged through the central exhaust port.
    • .png

    General paramters of our scroll oil free air compressor

    Model No.Air flowPowerPressureAirend qty.VoltagePhaseRemark
    m3/minkwMpaunitv/hz/
    MS-3/08-A10.3/0.230.8/1.01*3220/50single/
    M-3.7/08-A10.4/0.33.70.8/1.01*3.7380/503-pahse/
    MT-3.7/08-A10.4/0.33.70.8/1.01*3.7380/503-pahseTank mounted 200L
    M-7.5/08-A20.8/0.67.50.8/1.02*3.7380/503-pahse/
    M-5.5/08-S10.6/0.45.50.8/1.01*5.5380/503-pahse/
    MTI-5.5/08-S10.6/0.45.50.8/1.01*5.5380/503-pahseTank inside 100L
    MT-5.5/08-S10.6/0.45.50.8/1.01*5.5380/503-pahseTank mounted 200L
    M-11/08-S21.2/0.8110.8/1.02*5.5380/503-pahse/
    MTI-11/08-S21.2/0.8110.8/1.02*5.5380/503-pahseTank inside 200L
    M-16/08-S31.8/1.2160.8/1.03*5.5380/503-pahse/
    M-22/08-S42.4/1.6220.8/1.04*5.5380/503-pahse/
    M-27/08-S53.0/2.0270.8/1.05*5.5380/503-pahseTank inside 20L
    M-33/08-S63.6/2.4330.8/1.06*5.5380/503-pahse/
    M-38/0.8-S74.2/2.8380.8/1.07*5.5380/503-pahseTank inside 20L
    M-44/08-S84.8/3.2440.8/1.08*5.5380/503-pahse/
    M-49/08-S95.4/3.6490.8/1.09*5.5380/503-pahseTank inside 20L
